NB4L7210MNTXG
RoHS
/
Package 52-VFQFN
Category Integrated Circuits (ICs) / Clock/Timing - Clock Buffers, Drivers
Description
QUAD Surface Mount Fanout Buffer (Distribution) Multiplexer Tin (Sn) Clock Fanout Buffer (Distribution), Multiplexer IC -40C~85C 2GHz 0.2ns 3.3V
PDF
/
Buying Options
Total Price: USD $141.86
Unit Price: USD $141.8616
≥1 USD $141.8616
≥10 USD $137.1325
≥100 USD $122.9471
Inventory: 1108
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status RoHS Compliant
Radiation Hardening No
Dimensions
Width 8mm
Length 8mm
Technical
Same Edge Skew-Max (tskwd) 0.2 ns
Propagation Delay (tpd) 20 ns
Prop. Delay@Nom-Sup 30.8 ns
Differential - Input:Output Yes/Yes
Ratio - Input:Output 2:10
Input CML, LVCMOS, LVDS, LVPECL, LVTTL
Halogen Free Halogen Free
Family 4L
Frequency (Max) 2GHz
Number of Circuits 1
Supply Voltage-Min (Vsup) 2.375V
Supply Voltage-Max (Vsup) 3.6V
Operating Supply Voltage 3.3V
Pin Count 52
Output LVPECL
Terminal Pitch 0.5mm
Supply Voltage 2.5V
Number of Functions 1
Terminal Position QUAD
Voltage - Supply 2.375V~3.6V
Subcategory Clock Drivers
Terminal Finish Tin (Sn)
Type Fanout Buffer (Distribution), Multiplexer
Number of Terminations 52
Moisture Sensitivity Level (MSL) 2 (1 Year)
Part Status Obsolete
Pbfree Code yes
JESD-609 Code e3
Published 2007
Packaging Tape & Reel (TR)
Operating Temperature -40°C~85°C
Physical
Number of Pins 52
Package / Case 52-VFQFN
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 14 Weeks
