NB3H83905CMNG
RoHS
RoHS compliant
RoHS compliantPackage 20-VFQFN Exposed Pad
Category Integrated Circuits (ICs) / Clock/Timing - Clock Buffers, Drivers
Description
LVCMOS LVTTL Crystal 20-VFQFN Exposed Pad ACTIVE (Last Updated: 2days ago) Active clock buffer 4mm 10mA 100MHz -40C~85C
PDF
/
Buying Options
Total Price: USD $2.76
Unit Price: USD $2.7632
≥1 USD $2.7632
≥10 USD $2.4816
≥100 USD $2.033178
≥500 USD $1.92889
≥1000 USD $1.730793
≥3000 USD $1.459709
Inventory: 173
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 4 Weeks
Lifecycle Status ACTIVE (Last Updated: 2 days ago)
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 20-VFQFN Exposed Pad
Number of Pins 20
Technical
Operating Temperature -40°C~85°C
Packaging Tube
Published 2006
JESD-609 Code e3
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 20
ECCN Code EAR99
Type Fanout Buffer (Distribution)
Terminal Finish MATTE TIN
Voltage - Supply 1.6V~3.465V
Terminal Position QUAD
Supply Voltage 3.3V
Terminal Pitch 0.5mm
Frequency 100MHz
Output LVCMOS, LVTTL
Pin Count 20
Number of Outputs 6
Number of Circuits 1
Operating Supply Current 10mA
Quiescent Current 10mA
Logic Function Buffer, Clock
Halogen Free Halogen Free
Input LVCMOS, LVTTL, Crystal
Ratio - Input:Output 1:6
Primary Clock/Crystal Frequency-Nom 100MHz
Differential - Input:Output No/No
Max Duty Cycle 53 %
Duty Cycle 53 %
Dimensions
Height 950μm
Length 4mm
Width 4mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Lead Free
