NB100LVEP221MNRG
RoHS
RoHS compliant
RoHS compliantPackage 52-VFQFN Exposed Pad
Category Integrated Circuits (ICs) / Clock/Timing - Clock Buffers, Drivers
Description
NECL MODE: VCC = 0V WITH VEE = -2.375V TO -3.8V ECL HSTL LVPECL NB100LVEP221 52-VFQFN Exposed Pad clock buffer 8mm 2.5V 0.05ns 1GHz
PDF
/
Buying Options
Total Price: USD $18.07
Unit Price: USD $18.0664
≥1 USD $18.0664
≥10 USD $16.66544
≥100 USD $15.916736
≥500 USD $13.575936
≥1000 USD $12.920547
≥3000 USD $11.984262
Inventory: 2090
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Width 8mm
Length 8mm
Technical
Same Edge Skew-Max (tskwd) 0.05 ns
Differential - Input:Output Yes/Yes
Ratio - Input:Output 2:20
Input ECL, HSTL, LVPECL
Halogen Free Halogen Free
Frequency (Max) 1GHz
Number of Circuits 1
Supply Voltage-Min (Vsup) 2.375V
Supply Voltage-Max (Vsup) 3.8V
Pin Count 52
Output ECL, PECL
Base Part Number NB100LVEP221
Terminal Pitch 0.5mm
Supply Voltage 2.5V
Number of Functions 1
Terminal Position QUAD
Voltage - Supply 2.375V~3.8V
Technology ECL
Additional Feature NECL MODE: VCC = 0V WITH VEE = -2.375V TO -3.8V
Terminal Finish Tin (Sn)
Type Fanout Buffer (Distribution), Multiplexer
Number of Terminations 52
Moisture Sensitivity Level (MSL) 2 (1 Year)
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Series 100LVEP
Published 2005
Packaging Tape & Reel (TR)
Operating Temperature -40°C~85°C
Physical
Number of Pins 52
Package / Case 52-VFQFN Exposed Pad
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 5 hours ago)
Factory Lead Time 7 Weeks
