MC10H645FNR2
RoHS
/
Package 28-LCC (J-Lead)
Category Integrated Circuits (ICs) / Clock/Timing - Clock Buffers, Drivers
Description
TTL MC10H645 28-LCC (J-Lead) Obsolete clock driver 4.57mm 0.024A 0.65ns 0C~85C
PDF
/
Buying Options
Total Price: USD $6.4
Unit Price: USD $6.3976
≥1 USD $6.3976
Inventory: 1183
Minimum: 1
-
+
Technical Details
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 28-LCC (J-Lead)
Number of Pins 28
Technical
Operating Temperature 0°C~85°C
Packaging Tape & Reel (TR)
Published 2006
JESD-609 Code e0
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 28
Type Fanout Buffer (Distribution), Multiplexer
Terminal Finish Tin/Lead (Sn/Pb)
Subcategory Clock Drivers
Technology ECL
Voltage - Supply 4.75V~5.25V
Terminal Position QUAD
Terminal Form J BEND
Peak Reflow Temperature (Cel) 240
Number of Functions 1
Supply Voltage 5V
Reach Compliance Code not_compliant
Time@Peak Reflow Temperature-Max (s) 30
Base Part Number MC10H645
Pin Count 28
Number of Outputs 9
Qualification Status Not Qualified
Operating Supply Voltage 5V
Power Supplies 5V
Number of Circuits 1
Propagation Delay 7.2 ns
Family 10H
Input TTL
Ratio - Input:Output 2:9
Max I(ol) 0.024 A
Differential - Input:Output Yes/Yes
Prop. Delay@Nom-Sup 6.2 ns
Same Edge Skew-Max (tskwd) 0.65 ns
Dimensions
Height Seated (Max) 4.57mm
Compliance
RoHS Status Non-RoHS Compliant
Lead Free Contains Lead
