MC100EP809FA
RoHS
/
Package 32-LQFP
Category Integrated Circuits (ICs) / Clock/Timing - Clock Buffers, Drivers
Description
100EP QUAD Not Qualified Surface Mount Clock Fanout Buffer (Distribution), Multiplexer IC 0C~85C 750MHz 0.05ns 3.3V
PDF
/
Buying Options
Total Price: USD $10.18
Unit Price: USD $10.17545
≥1 USD $10.17545
≥10 USD $8.34955
≥100 USD $8.0883
≥500 USD $7.828
≥1000 USD $7.56675
Inventory: 9100
Minimum: 1
-
+
Technical Details
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 32-LQFP
Number of Pins 32
Technical
Operating Temperature 0°C~85°C
Packaging Tray
Published 2007
Series 100EP
JESD-609 Code e0
Pbfree Code no
Part Status Obsolete
Moisture Sensitivity Level (MSL) 2 (1 Year)
Number of Terminations 32
Type Fanout Buffer (Distribution), Multiplexer
Terminal Finish Tin/Lead (Sn/Pb)
Subcategory Clock Drivers
Technology ECL
Voltage - Supply 3V~3.6V
Terminal Position QUAD
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 240
Number of Functions 1
Supply Voltage 3.3V
Terminal Pitch 0.8mm
Reach Compliance Code not_compliant
Time@Peak Reflow Temperature-Max (s) 30
Base Part Number MC100EP809
Output HSTL
Pin Count 32
Qualification Status Not Qualified
Operating Supply Voltage 3.3V
Supply Voltage-Max (Vsup) 3.6V
Supply Voltage-Min (Vsup) 3V
Number of Circuits 2
Frequency (Max) 750MHz
Input HSTL, LVDS, LVPECL
Ratio - Input:Output 1:9
Differential - Input:Output Yes/Yes
Propagation Delay (tpd) 1 ns
fmax-Min 500 MHz
Same Edge Skew-Max (tskwd) 0.05 ns
Dimensions
Height Seated (Max) 1.6mm
Length 7mm
Width 7mm
Compliance
RoHS Status Non-RoHS Compliant
Lead Free Contains Lead
