MC100EP14DT
RoHS
/
Package 20-TSSOP (0.173, 4.40mm Width)
Category Integrated Circuits (ICs) / Clock/Timing - Clock Buffers, Drivers
Description
100EP DUAL Surface Mount ECL Clock Fanout Buffer (Distribution), Multiplexer IC -40C~85C 2GHz 0.045ns -4.5V
PDF
/
Buying Options
Total Price: USD $8.76
Unit Price: USD $8.7628
≥1 USD $8.7628
≥10 USD $7.1896
≥100 USD $6.9654
≥500 USD $6.74025
≥1000 USD $6.51605
Inventory: 6047
Minimum: 1
-
+
Technical Details
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 20-TSSOP (0.173, 4.40mm Width)
Number of Pins 20
Technical
Operating Temperature -40°C~85°C
Packaging Tube
Published 2006
Series 100EP
JESD-609 Code e4
Pbfree Code yes
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 20
ECCN Code EAR99
Type Fanout Buffer (Distribution), Multiplexer
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Additional Feature NECL MODE: VCC = 0V WITH VEE = -3V TO -5.5V
Subcategory Clock Drivers
Technology ECL
Voltage - Supply 3V~5.5V
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Number of Functions 1
Supply Voltage 3.3V
Terminal Pitch 0.65mm
Time@Peak Reflow Temperature-Max (s) 40
Base Part Number MC100EP14
Output ECL, PECL
Pin Count 20
Supply Voltage-Max (Vsup) 5.5V
Power Supplies -4.5V
Supply Voltage-Min (Vsup) 3V
Number of Circuits 1
Frequency (Max) 2GHz
Input ECL, HSTL, PECL
Ratio - Input:Output 2:5
Differential - Input:Output Yes/Yes
Prop. Delay@Nom-Sup 0.6 ns
Propagation Delay (tpd) 0.45 ns
Same Edge Skew-Max (tskwd) 0.045 ns
Dimensions
Length 6.5mm
Width 4.4mm
Compliance
Radiation Hardening No
RoHS Status Non-RoHS Compliant
Lead Free Lead Free
