MC100E210FNR2
RoHS
/
Package 28-LCC (J-Lead)
Category Integrated Circuits (ICs) / Clock/Timing - Clock Buffers, Drivers
Description
ECL PECL MC100E210 28-LCC (J-Lead) Obsolete clock driver 11.505mm -4.5V 0.075ns 700MHz
PDF
/
Inventory: 1704
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Contains Lead
RoHS Status Non-RoHS Compliant
Dimensions
Width 11.505mm
Length 11.505mm
Height Seated (Max) 4.57mm
Technical
Same Edge Skew-Max (tskwd) 0.075 ns
Prop. Delay@Nom-Sup 0.75 ns
Differential - Input:Output Yes/Yes
Ratio - Input:Output 1:4, 1:5
Input ECL, PECL
Frequency (Max) 700MHz
Propagation Delay 750 ps
Number of Circuits 2
Power Supplies -4.5V
Supply Voltage-Max (Vsup) 5.7V
Qualification Status Not Qualified
Number of Outputs 18
Pin Count 28
Output ECL, PECL
Base Part Number MC100E210
Time@Peak Reflow Temperature-Max (s) 30
Reach Compliance Code not_compliant
Supply Voltage 5V
Number of Functions 2
Peak Reflow Temperature (Cel) 240
Terminal Form J BEND
Terminal Position QUAD
Voltage - Supply 4.2V~5.7V
Technology ECL
Subcategory Clock Drivers
Terminal Finish Tin/Lead (Sn/Pb)
Type Fanout Buffer (Distribution)
Number of Terminations 28
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Obsolete
JESD-609 Code e0
Series 100E
Published 2008
Packaging Tape & Reel (TR)
Operating Temperature 0°C~85°C
Physical
Number of Pins 28
Package / Case 28-LCC (J-Lead)
Mounting Type Surface Mount
Mount Surface Mount
