SY58021UMG-TR
RoHS
RoHS compliant
RoHS compliantPackage 16-VFQFN Exposed Pad, 16-MLF?
Category Integrated Circuits (ICs) / Clock/Timing - Clock Buffers, Drivers
Description
IT ALSO OPERATE ON 3.3V SUPPLY CML LVDS LVPECL SY58021 16-VFQFN Exposed Pad 16-MLF? clock driver 3mm 2.5V 0.3ns 4GHz
PDF
/
Buying Options
Total Price: USD $8.62
Unit Price: USD $8.624
≥1 USD $8.624
≥10 USD $7.172
≥100 USD $6.5384
Inventory: 1197
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Width 3mm
Length 3mm
Height Seated (Max) 0.9mm
Technical
Prop. Delay@Nom-Sup 0.3 ns
Differential - Input:Output Yes/Yes
Ratio - Input:Output 1:4
Input CML, LVDS, LVPECL
Data Rate 5 Gbps
Frequency (Max) 4GHz
Turn On Delay Time 300 ps
Propagation Delay 300 ps
Number of Circuits 1
Supply Voltage-Min (Vsup) 2.375V
Supply Voltage-Max (Vsup) 2.625V
Number of Outputs 4
Output LVPECL
Base Part Number SY58021
Terminal Pitch 0.5mm
Supply Voltage 2.5V
Number of Functions 1
Terminal Position QUAD
Voltage - Supply 2.375V~3.6V
Packing Method TR
Additional Feature IT ALSO OPERATE ON 3.3V SUPPLY
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Type Fanout Buffer (Distribution), Translator
Number of Terminations 16
Moisture Sensitivity Level (MSL) 2 (1 Year)
Part Status Active
JESD-609 Code e4
Series Precision Edge?
Packaging Tape & Reel (TR)
Operating Temperature -40°C~85°C
Physical
Number of Pins 16
Package / Case 16-VFQFN Exposed Pad, 16-MLF?
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 8 Weeks
