IDT74FCT3807DPYGI
RoHS
/
Package SSOP
Category Integrated Circuits (ICs) / Clock/Timing - Clock Buffers, Drivers
Description
DUAL Not Qualified INDUSTRIAL Surface Mount clock buffer 85C 166MHz 0.25ns 3.6V
PDF
/
Buying Options
Total Price: USD $9.68
Unit Price: USD $9.67765
≥1 USD $9.67765
≥10 USD $7.94105
≥100 USD $7.69215
≥500 USD $7.4442
≥1000 USD $7.19625
Inventory: 1956
Minimum: 1
-
+
Technical Details
Physical
Mount Surface Mount
Package / Case SSOP
Number of Pins 20
Technical
JESD-609 Code e3
Pbfree Code yes
Moisture Sensitivity Level (MSL) 1
Number of Terminations 20
ECCN Code EAR99
Terminal Finish Matte Tin (Sn) - annealed
Max Operating Temperature 85°C
Min Operating Temperature -40°C
Technology CMOS
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Number of Functions 1
Supply Voltage 3.3V
Terminal Pitch 0.65mm
Time@Peak Reflow Temperature-Max (s) 30
Pin Count 20
Qualification Status Not Qualified
Temperature Grade INDUSTRIAL
Number of Circuits 1
Max Supply Voltage 3.6V
Min Supply Voltage 3V
Frequency (Max) 166MHz
Family FCT
Logic Function Clock
Input LVTTL
Prop. Delay@Nom-Sup 2.5 ns
Propagation Delay (tpd) 2.5 ns
Same Edge Skew-Max (tskwd) 0.25 ns
Number of True Outputs 10
Dimensions
Height 1.73mm
Length 7.2mm
Width 5.3mm
Compliance
RoHS Status RoHS Compliant
Lead Free Lead Free
