IDT49FCT805CTPY
RoHS
/
Package SSOP
Category Integrated Circuits (ICs) / Clock/Timing - Clock Buffers, Drivers
Description
DUAL Not Qualified COMMERCIAL Surface Mount Clock (Type) IC 70C 100MHz 0.5ns 0.048A
PDF
/
Buying Options
Total Price: USD $44.1
Unit Price: USD $44.1028
≥1 USD $44.1028
≥10 USD $36.1874
≥100 USD $35.05595
≥500 USD $33.92545
≥1000 USD $32.79495
Inventory: 1150
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status RoHS Compliant
Dimensions
Width 5.3mm
Height Seated (Max) 1.99mm
Technical
Number of True Outputs 5
Same Edge Skew-Max (tskwd) 0.5 ns
Propagation Delay (tpd) 4.5 ns
Prop. Delay@Nom-Sup 4.5 ns
Max I(ol) 0.048 A
Logic IC Type LOW SKEW CLOCK DRIVER
Input LVTTL
Output Characteristics 3-STATE
Family FCT
Frequency (Max) 100MHz
Number of Circuits 2
Supply Voltage-Min (Vsup) 4.5V
Temperature Grade COMMERCIAL
Power Supplies 5V
Supply Voltage-Max (Vsup) 5.5V
Qualification Status Not Qualified
Pin Count 20
Time@Peak Reflow Temperature-Max (s) 30
Terminal Pitch 0.65mm
Supply Voltage 5V
Number of Functions 2
Peak Reflow Temperature (Cel) 225
Terminal Form GULL WING
Terminal Position DUAL
Technology CMOS
Subcategory Clock Drivers
Min Operating Temperature 0°C
Max Operating Temperature 70°C
Terminal Finish Tin/Lead (Sn85Pb15)
Number of Terminations 20
Moisture Sensitivity Level (MSL) 1
JESD-609 Code e0
Published 2009
Physical
Package / Case SSOP
Mount Surface Mount
