IDT49FCT805APYI
RoHS
/
Package SSOP
Category Integrated Circuits (ICs) / Clock/Timing - Clock Buffers, Drivers
Description
DUAL Not Qualified INDUSTRIAL Surface Mount Clock (Type) IC 85C 80MHz 0.7ns 0.064A
PDF
/
Buying Options
Total Price: USD $3.35
Unit Price: USD $3.34556
≥1 USD $3.34556
≥10 USD $3.15619
≥100 USD $2.97754
≥500 USD $2.809
≥1000 USD $2.65
≥3000 USD $2.5
Inventory: 3102
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status Non-RoHS Compliant
Dimensions
Width 5.3mm
Height Seated (Max) 1.99mm
Technical
Number of True Outputs 5
Same Edge Skew-Max (tskwd) 0.7 ns
Propagation Delay (tpd) 5.3 ns
Prop. Delay@Nom-Sup 5.3 ns
Max I(ol) 0.064 A
Logic IC Type LOW SKEW CLOCK DRIVER
Input LVTTL
Output Characteristics 3-STATE
Family FCT
Frequency (Max) 80MHz
Number of Circuits 2
Supply Voltage-Min (Vsup) 4.75V
Temperature Grade INDUSTRIAL
Power Supplies 5V
Qualification Status Not Qualified
Pin Count 20
Time@Peak Reflow Temperature-Max (s) 30
Reach Compliance Code not_compliant
Terminal Pitch 0.65mm
Supply Voltage 5V
Number of Functions 2
Peak Reflow Temperature (Cel) 225
Terminal Form GULL WING
Terminal Position DUAL
Technology CMOS
Subcategory Clock Drivers
Additional Feature MONITOR OUTPUT; MAX PART TO PART SKEW = 1.5NS
Min Operating Temperature -40°C
Max Operating Temperature 85°C
Terminal Finish Tin/Lead (Sn85Pb15)
Number of Terminations 20
Moisture Sensitivity Level (MSL) 1
JESD-609 Code e0
Published 2009
Physical
Package / Case SSOP
Mount Surface Mount
