ICS83940DYLFT
RoHS
/
Package LQFP
Category Integrated Circuits (ICs) / Clock/Timing - Clock Buffers, Drivers
Description
QUAD Not Qualified COMMERCIAL Surface Mount clock buffer 70C 250MHz 0.2ns 0.02A
PDF
/
Buying Options
Total Price: USD $22.12
Unit Price: USD $22.1198
≥1 USD $22.1198
≥10 USD $18.14975
≥100 USD $17.5826
≥500 USD $17.01545
≥1000 USD $16.4483
Inventory: 1684
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status RoHS Compliant
Dimensions
Width 7mm
Length 7mm
Technical
Number of True Outputs 18
Same Edge Skew-Max (tskwd) 0.2 ns
Propagation Delay (tpd) 3.8 ns
Prop. Delay@Nom-Sup 3.8 ns
Max I(ol) 0.02 A
Logic IC Type LOW SKEW CLOCK DRIVER
Input LVTTL
Family 83940
Frequency (Max) 250MHz
Number of Circuits 1
Supply Voltage-Min (Vsup) 2.375V
Temperature Grade COMMERCIAL
Power Supplies 2.5/3.33.3V
Supply Voltage-Max (Vsup) 2.625V
Qualification Status Not Qualified
JESD-30 Code S-PQFP-G32
Pin Count 32
Time@Peak Reflow Temperature-Max (s) 30
Terminal Pitch 0.8mm
Supply Voltage 2.5V
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position QUAD
Subcategory Clock Drivers
Additional Feature ALSO OPERATES AT 3.3V SUPPLY
Min Operating Temperature 0°C
Max Operating Temperature 70°C
Terminal Finish Matte Tin (Sn) - annealed
Number of Terminations 32
Moisture Sensitivity Level (MSL) 3
Pbfree Code yes
JESD-609 Code e3
Packaging Tape & Reel (TR)
Physical
Package / Case LQFP
Mount Surface Mount
