ICS8302AMILFT
RoHS
/
Package SOIC
Category Integrated Circuits (ICs) / Clock/Timing - Clock Buffers, Drivers
Description
DUAL Not Qualified INDUSTRIAL Surface Mount clock driver 85C 200MHz 3.3ns 2.5/3.33.3V
PDF
/
Buying Options
Total Price: USD $40.27
Unit Price: USD $40.2724
≥1 USD $40.2724
≥10 USD $33.04385
≥100 USD $32.0112
≥500 USD $30.97855
≥1000 USD $29.9459
Inventory: 3208
Minimum: 1
-
+
Technical Details
Physical
Mount Surface Mount
Package / Case SOIC
Technical
Packaging Tape & Reel (TR)
JESD-609 Code e3
Pbfree Code yes
Moisture Sensitivity Level (MSL) 1
Number of Terminations 8
Terminal Finish Matte Tin (Sn) - annealed
Max Operating Temperature 85°C
Min Operating Temperature -40°C
Additional Feature ALSO OPERATES AT 2.5V OUTPUT SUPPLY
Subcategory Clock Drivers
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Number of Functions 1
Supply Voltage 3.3V
Time@Peak Reflow Temperature-Max (s) 30
Pin Count 8
JESD-30 Code R-PDSO-G8
Qualification Status Not Qualified
Supply Voltage-Max (Vsup) 3.465V
Power Supplies 2.5/3.33.3V
Temperature Grade INDUSTRIAL
Number of Circuits 1
Frequency (Max) 200MHz
Family 8302
Input LVTTL
Logic IC Type LOW SKEW CLOCK DRIVER
Prop. Delay@Nom-Sup 3.3 ns
Propagation Delay (tpd) 3.3 ns
Number of True Outputs 2
Dimensions
Length 4.9mm
Width 3.9mm
Compliance
RoHS Status RoHS Compliant
