RoHS
/
Package /
Category Integrated Circuits (ICs) / Clock/Timing - Clock Buffers, Drivers
Description
DIFFERENTIAL R-PDSO-G24 Tin/Lead (Sn85Pb15) LOW SKEW CLOCK DRIVER clock driver 4.4mm 3.465V 0.05ns 700MHz
PDF
/
Inventory: 1552
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status RoHS Compliant
Dimensions
Width 4.4mm
Length 7.8mm
Height Seated (Max) 1.2mm
Technical
Input Conditioning DIFFERENTIAL
Number of True Outputs 8
Same Edge Skew-Max (tskwd) 0.05 ns
fmax-Min 700 MHz
Propagation Delay (tpd) 2.4 ns
Prop. Delay@Nom-Sup 2.4 ns
Logic IC Type LOW SKEW CLOCK DRIVER
Output Characteristics 3-STATE
Family 85408
Min Supply Voltage 3.135V
Max Supply Voltage 3.465V
Temperature Grade COMMERCIAL
Operating Supply Voltage 3.3V
Operating Temperature (Max) 70°C
Qualification Status Not Qualified
JESD-30 Code R-PDSO-G24
Pin Count 24
Time@Peak Reflow Temperature-Max (s) 30
Terminal Pitch 0.65mm
Supply Voltage 3.3V
Number of Functions 1
Peak Reflow Temperature (Cel) 225
Terminal Form GULL WING
Terminal Position DUAL
Subcategory Clock Drivers
HTS Code 8542.39.00.01
Terminal Finish Tin/Lead (Sn85Pb15)
ECCN Code EAR99
Number of Terminations 24
Moisture Sensitivity Level (MSL) 1
Pbfree Code no
JESD-609 Code e0
Published 2007
Physical
Mount Surface Mount
Contact Plating Lead, Tin
