PI6C4911506LIEX
RoHS
RoHS compliant
RoHS compliantPackage 20-TSSOP (0.173, 4.40mm Width)
Category Integrated Circuits (ICs) / Clock/Timing - Clock Buffers, Drivers
Description
DUAL Surface Mount Fanout Buffer (Distribution) Active clock driver -40C~85C TA 1.5GHz 0.05ns 2.5V
PDF
/
Buying Options
Total Price: USD $10.74
Unit Price: USD $10.73975
≥1 USD $10.73975
≥10 USD $8.8122
≥100 USD $8.5367
≥500 USD $8.2612
≥1000 USD $7.9857
Inventory: 1293
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 4.4mm
Length 6.5mm
Technical
Same Edge Skew-Max (tskwd) 0.05 ns
Propagation Delay (tpd) 0.7 ns
Differential - Input:Output Yes/Yes
Ratio - Input:Output 1:6
Input CMOS, LVDS, LVPECL
Family 6C
Frequency (Max) 1.5GHz
Number of Circuits 1
Supply Voltage-Min (Vsup) 2.375V
Supply Voltage-Max (Vsup) 2.625V
JESD-30 Code R-PDSO-G20
Output LVPECL
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Terminal Pitch 0.65mm
Supply Voltage 2.5V
Number of Functions 1
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Form GULL WING
Terminal Position DUAL
Voltage - Supply 2.375V~2.625V 3V~3.6V
Additional Feature ALSO OPERATES AT 3 TO 3.6 V SUPPLY
Type Fanout Buffer (Distribution)
ECCN Code EAR99
Number of Terminations 20
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Packaging Tape & Reel (TR)
Operating Temperature -40°C~85°C TA
Physical
Surface Mount YES
Package / Case 20-TSSOP (0.173, 4.40mm Width)
Mounting Type Surface Mount
Supply Chain
Factory Lead Time 20 Weeks
