PI49FCT20803LE

Diodes Incorporated
RoHS
RoHS RoHS compliant
Package 16-TSSOP (0.173, 4.40mm Width)
Category Integrated Circuits (ICs) / Clock/Timing - Clock Buffers, Drivers
Description CMOS TTL 49FCT20803 16-TSSOP (0.173 4.40mm Width) Obsolete clock driver 4.4mm 2.5V 3.5ns 500mW
PDF
/
Buying Options
Total Price: USD $0.81
Unit Price: USD $0.8056
≥1 USD $0.8056
≥10 USD $0.6612
≥100 USD $0.6403
≥500 USD $0.62035
≥1000 USD $0.59945
Inventory: 14662
Minimum: 1
-
+

Technical Details

Compliance

Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No

Dimensions

Width 4.4mm
Length 5mm

Technical

Differential - Input:Output No/No
Max I(ol) 0.008 A
Ratio - Input:Output 1:7
Input CMOS, TTL
Family FCT
Frequency (Max) 150MHz
Turn On Delay Time 3.5 ns
Quiescent Current 100nA
Propagation Delay 3.5 ns
Power Dissipation 500mW
Number of Circuits 1
Supply Voltage-Min (Vsup) 2.3V
Operating Supply Voltage 2.5V
Number of Outputs 7
Output CMOS, TTL
Base Part Number 49FCT20803
Time@Peak Reflow Temperature-Max (s) 30
Terminal Pitch 0.65mm
Supply Voltage 2.5V
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Voltage - Supply 2.3V~2.7V
Max Power Dissipation 500mW
Subcategory Clock Drivers
Terminal Finish Matte Tin (Sn)
Type Fanout Buffer (Distribution)
ECCN Code EAR99
Number of Terminations 16
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
JESD-609 Code e3
Series 49FCT
Published 2011
Packaging Tube
Operating Temperature -40°C~85°C

Physical

Number of Pins 16
Package / Case 16-TSSOP (0.173, 4.40mm Width)
Mounting Type Surface Mount
Mount Surface Mount

Supply Chain

Factory Lead Time 7 Weeks
