CY2CC910OIT
RoHS
/
Package SSOP
Category Integrated Circuits (ICs) / Clock/Timing - Clock Buffers, Drivers
Description
DUAL Not Qualified INDUSTRIAL Surface Mount clock driver 85C 750mW 0.2ns 0.012A
PDF
/
Buying Options
Total Price: USD $1.98
Unit Price: USD $1.98
≥1 USD $1.98
Inventory: 1398
Minimum: 1
-
+
Technical Details
Physical
Mount Surface Mount
Package / Case SSOP
Number of Pins 20
Technical
JESD-609 Code e0
Moisture Sensitivity Level (MSL) 3
Number of Terminations 20
Terminal Finish TIN LEAD
Max Operating Temperature 85°C
Min Operating Temperature -40°C
Additional Feature ALSO OPERATES WITH 2.5V AND 3.3V SUPPLY
HTS Code 8542.39.00.01
Subcategory Clock Drivers
Technology CMOS
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 220
Number of Functions 1
Supply Voltage 1.8V
Terminal Pitch 0.65mm
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Pin Count 20
Number of Outputs 10
Qualification Status Not Qualified
Power Supplies 1.8/3.3V
Temperature Grade INDUSTRIAL
Max Supply Voltage 3.465V
Min Supply Voltage 1.71V
Power Dissipation 750mW
Propagation Delay 3.5 ns
Quiescent Current 25mA
Family 2CC
Logic IC Type LOW SKEW CLOCK DRIVER
Max I(ol) 0.012 A
Same Edge Skew-Max (tskwd) 0.2 ns
Input Conditioning SCHMITT TRIGGER
Dimensions
Height Seated (Max) 2mm
Length 7.2mm
Width 5.3mm
Compliance
RoHS Status RoHS Compliant
