CY2DP818ZC
RoHS
/
Package 38-TFSOP (0.173, 4.40mm Width)
Category Integrated Circuits (ICs) / Clock/Timing - Clock Buffers, Drivers
Description
DUAL Not Qualified Surface Mount CMOS Clock Fanout Buffer (Distribution) IC 0C~70C 350MHz 0.2ns 3.3V
PDF
/
Buying Options
Total Price: USD $3.18
Unit Price: USD $3.183783
≥1 USD $3.183783
≥200 USD $1.232813
≥500 USD $1.189487
≥1000 USD $1.167168
Inventory: 9603
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status Non-RoHS Compliant
Dimensions
Width 4.4mm
Length 9.7mm
Technical
Same Edge Skew-Max (tskwd) 0.2 ns
Propagation Delay (tpd) 5 ns
Prop. Delay@Nom-Sup 5 ns
Differential - Input:Output Yes/Yes
Ratio - Input:Output 1:8
Input LVDS, LVPECL, LVTTL
Family 2DP
Frequency (Max) 350MHz
Number of Circuits 1
Power Supplies 3.3V
Supply Voltage-Max (Vsup) 3.465V
Qualification Status Not Qualified
JESD-30 Code R-PDSO-G38
Pin Count 38
Output LVPECL
Base Part Number CY2DP818
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Reach Compliance Code not_compliant
Terminal Pitch 0.5mm
Supply Voltage 3.3V
Number of Functions 1
Peak Reflow Temperature (Cel) 220
Terminal Form GULL WING
Terminal Position DUAL
Voltage - Supply 3.135V~3.465V
Technology CMOS
Subcategory Clock Drivers
Terminal Finish Tin/Lead (Sn/Pb)
Type Fanout Buffer (Distribution)
Number of Terminations 38
Moisture Sensitivity Level (MSL) 2 (1 Year)
Part Status Obsolete
JESD-609 Code e0
Published 1999
Packaging Tube
Operating Temperature 0°C~70°C
Physical
Package / Case 38-TFSOP (0.173, 4.40mm Width)
Mounting Type Surface Mount
Mount Surface Mount
