CDCF2510PWR
RoHS
RoHS compliant
RoHS compliantPackage 24-TSSOP (0.173, 4.40mm Width)
Category Integrated Circuits (ICs) / Clock/Timing - Application Specific
Description
GULL WING Obsolete BICMOS ROHS3Compliant Memory, DRAM DIMM IC e4 0C~85C 0.2ns 140MHz
PDF
/
Buying Options
Total Price: USD $5.46
Unit Price: USD $5.46345
≥1 USD $5.46345
≥10 USD $4.48305
≥100 USD $4.3434
≥500 USD $4.2028
≥1000 USD $4.06315
Inventory: 1686
Minimum: 1
-
+
Technical Details
Physical
Mounting Type Surface Mount
Package / Case 24-TSSOP (0.173, 4.40mm Width)
Surface Mount YES
Technical
Operating Temperature 0°C~85°C
Packaging Tape & Reel (TR)
JESD-609 Code e4
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 24
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Technology BICMOS
Voltage - Supply 3V~3.6V
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Number of Functions 1
Supply Voltage 3.3V
Terminal Pitch 0.65mm
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Base Part Number CDCF2510
Pin Count 24
JESD-30 Code R-PDSO-G24
Qualification Status Not Qualified
Supply Voltage-Max (Vsup) 3.6V
Power Supplies 3.3V
Supply Voltage-Min (Vsup) 3V
Number of Circuits 1
Frequency (Max) 140MHz
Output Characteristics SERIES-RESISTOR
Input Clock
Ratio - Input:Output 1:10
PLL Yes
Differential - Input:Output No/No
Main Purpose Memory, DRAM DIMM
Same Edge Skew-Max (tskwd) 0.2 ns
Number of True Outputs 10
Dimensions
Length 7.8mm
Width 4.4mm
Compliance
RoHS Status ROHS3 Compliant
