CDCF2509PW
RoHS
RoHS compliant
RoHS compliantPackage 24-TSSOP (0.173, 4.40mm Width)
Category Integrated Circuits (ICs) / Clock/Timing - Application Specific
Description
Gold GULL WING Obsolete BICMOS Memory, DRAM DIMM IC e4 700mW 0C~85C 0.2ns
PDF
/
Buying Options
Total Price: USD $6.71
Unit Price: USD $6.7127
≥1 USD $6.7127
≥10 USD $5.5081
≥100 USD $5.3352
≥500 USD $5.16325
≥1000 USD $4.9913
Inventory: 11459
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Contains Lead
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Width 4.4mm
Length 7.8mm
Technical
Same Edge Skew-Max (tskwd) 0.2 ns
Main Purpose Memory, DRAM DIMM
Differential - Input:Output No/No
PLL Yes
Ratio - Input:Output 1:9
Input Clock
Output Characteristics 3-STATE WITH SERIES RESISTOR
Quiescent Current 10μA
Power Dissipation 700mW
Nominal Supply Current 10μA
Number of Circuits 1
Supply Voltage-Min (Vsup) 3V
Supply Voltage-Max (Vsup) 3.6V
Operating Supply Voltage 3.3V
Number of Outputs 9
Pin Count 24
Base Part Number CDCF2509
Frequency 140MHz
Terminal Pitch 0.65mm
Supply Voltage 3.3V
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Voltage - Supply 3V~3.6V
Technology BICMOS
Number of Terminations 24
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code no
JESD-609 Code e4
Packaging Tube
Operating Temperature 0°C~85°C
Physical
Weight 89.499445mg
Number of Pins 24
Package / Case 24-TSSOP (0.173, 4.40mm Width)
Mounting Type Surface Mount
Mount Surface Mount
Contact Plating Gold
