CDC924DLRG4
RoHS
RoHS compliant
RoHS compliantPackage 56-BSSOP (0.295, 7.50mm Width)
Category Integrated Circuits (ICs) / Clock/Timing - Application Specific
Description
Gold GULL WING Obsolete Contains Lead Intel CPU Servers IC e4 0C~85C 133MHz 3.3V
PDF
/
Inventory: 6562
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Contains Lead
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Width 7.49mm
Technical
Main Purpose Intel CPU Servers
Differential - Input:Output No/No
PLL Yes
Primary Clock/Crystal Frequency-Nom 14.318MHz
Ratio - Input:Output 1:24
Input Crystal
uPs/uCs/Peripheral ICs Type CLOCK GENERATOR, PROCESSOR SPECIFIC
Nominal Supply Current 35mA
Number of Circuits 1
Number of Elements 2
Number of Outputs 24
Pin Count 56
Output CMOS
Base Part Number CDC924
Frequency 133MHz
Terminal Pitch 0.635mm
Supply Voltage 3.3V
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Voltage - Supply 2.375V~3.465V
Subcategory Clock Generators
ECCN Code EAR99
Number of Terminations 56
Moisture Sensitivity Level (MSL) 2 (1 Year)
Part Status Obsolete
Pbfree Code no
JESD-609 Code e4
Packaging Tape & Reel (TR)
Operating Temperature 0°C~85°C
Physical
Weight 694.790113mg
Number of Pins 56
Package / Case 56-BSSOP (0.295, 7.50mm Width)
Mounting Type Surface Mount
Mount Surface Mount
Contact Plating Gold
