SI5338P-B01918-GM
RoHS
/
Package 24-VFQFN Exposed Pad
Category Integrated Circuits (ICs) / Clock/Timing - Application Specific
Description
INDUSTRIAL NO LEAD Active CMOS (Main Purpose) IC 2 (1Year) 85C 350MHz 1.8V
PDF
/
Inventory: 9613
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 6 Weeks
Physical
Mounting Type Surface Mount
Package / Case 24-VFQFN Exposed Pad
Surface Mount YES
Technical
Packaging Tray
Part Status Active
Moisture Sensitivity Level (MSL) 2 (1 Year)
Number of Terminations 24
Additional Feature IT ALSO OPERATES AT 2.5V AND 3.3V NOMINAL
Technology CMOS
Terminal Position QUAD
Terminal Form NO LEAD
Peak Reflow Temperature (Cel) 260
Supply Voltage 1.8V
Terminal Pitch 0.5mm
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
JESD-30 Code S-XQCC-N24
Operating Temperature (Max) 85°C
Operating Temperature (Min) -40°C
Supply Voltage-Max (Vsup) 1.98V
Temperature Grade INDUSTRIAL
Supply Voltage-Min (Vsup) 1.71V
uPs/uCs/Peripheral ICs Type CLOCK GENERATOR, PROCESSOR SPECIFIC
Primary Clock/Crystal Frequency-Nom 30MHz
Output Clock Frequency-Max 350MHz
Dimensions
Height Seated (Max) 0.9mm
Length 4mm
Width 4mm
Compliance
RoHS Status Non-RoHS Compliant
