CY28346ZI-2
RoHS
/
Package 56-TFSOP (0.240, 6.10mm Width)
Category Integrated Circuits (ICs) / Clock/Timing - Application Specific
Description
56-TFSOP (0.240 6.10mm Width) Intel CPU Servers CY28346 CLOCK GENERATOR PROCESSOR SPECIFIC application specific IC 6.096mm 3.3V 200MHz 0C~85C
PDF
/
Buying Options
Total Price: USD $3.38
Unit Price: USD $3.3792
≥1 USD $3.3792
Inventory: 750
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 12 Weeks
Physical
Mounting Type Surface Mount
Package / Case 56-TFSOP (0.240, 6.10mm Width)
Surface Mount YES
Number of Pins 56
Weight 50.008559mg
Technical
Operating Temperature 0°C~85°C
Packaging Tube
Published 2003
Pbfree Code no
Part Status Obsolete
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 56
ECCN Code EAR99
Voltage - Supply 3.135V~3.465V
Terminal Position DUAL
Terminal Form GULL WING
Supply Voltage 3.3V
Terminal Pitch 0.5mm
Base Part Number CY28346
Output HCSL, LVCMOS
Pin Count 56
Operating Supply Voltage 3.3V
Number of Elements 2
Number of Circuits 1
uPs/uCs/Peripheral ICs Type CLOCK GENERATOR, PROCESSOR SPECIFIC
Frequency (Max) 200MHz
Input Crystal
Ratio - Input:Output 1:21
Primary Clock/Crystal Frequency-Nom 14.31818MHz
PLL Yes
Differential - Input:Output No/Yes
Main Purpose Intel CPU Servers
Dimensions
Width 6.096mm
Compliance
Radiation Hardening No
RoHS Status RoHS Compliant
