ADN2811ACP-CML
RoHS
/
Package 48-VFQFN Exposed Pad, CSP
Category Integrated Circuits (ICs) / Clock/Timing - Application Specific
Description
NO LEAD Obsolete Non-RoHS Compliant S-XQCC-N48 SONET/SDH, STM IC e0 -40C~85C 2.66GHz 3.3V
PDF
/
Buying Options
Total Price: USD $58.09
Unit Price: USD $58.0888
≥1 USD $58.0888
Inventory: 512
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status Non-RoHS Compliant
Dimensions
Width 7mm
Length 7mm
Height Seated (Max) 1mm
Technical
Main Purpose SONET/SDH, STM
Telecom IC Type CLOCK RECOVERY CIRCUIT
Differential - Input:Output Yes/Yes
PLL Yes
Ratio - Input:Output 1:2
Input CML
Frequency (Max) 2.66GHz
Qualification Status COMMERCIAL
JESD-30 Code S-XQCC-N48
Pin Count 48
Time@Peak Reflow Temperature-Max (s) 30
Terminal Pitch 0.5mm
Supply Voltage 3.3V
Number of Functions 1
Peak Reflow Temperature (Cel) 240
Terminal Form NO LEAD
Terminal Position QUAD
Voltage - Supply 3V~3.6V
Terminal Finish TIN LEAD
Number of Terminations 48
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Obsolete
Pbfree Code no
JESD-609 Code e0
Packaging Tray
Operating Temperature -40°C~85°C
Physical
Surface Mount YES
Package / Case 48-VFQFN Exposed Pad, CSP
Mounting Type Surface Mount
