MC100H640FN
RoHS
/
Package 28-LCC (J-Lead)
Category Integrated Circuits (ICs) / Clock/Timing - Application Specific
Description
J BEND Obsolete ECL Contains Lead 68030, 68040 MPUs IC e0 0C~85C 6ns 135MHz
PDF
/
Buying Options
Total Price: USD $9.82
Unit Price: USD $9.8192
≥1 USD $9.8192
≥10 USD $8.05695
≥100 USD $7.8052
≥500 USD $7.55345
≥1000 USD $7.3017
Inventory: 1548
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Contains Lead
RoHS Status Non-RoHS Compliant
Dimensions
Height Seated (Max) 4.57mm
Technical
Same Edge Skew-Max (tskwd) 0.5 ns
Main Purpose 68030, 68040 MPUs
Propagation Delay (tpd) 6 ns
Prop. Delay@Nom-Sup 7 ns
Differential - Input:Output Yes/Yes
PLL No
Max I(ol) 0.024 A
Logic IC Type LOW SKEW CLOCK DRIVER
Ratio - Input:Output 2:6
Input PECL, TTL
Frequency (Max) 135MHz
Number of Circuits 1
Supply Voltage-Min (Vsup) 4.75V
Power Supplies 5V
Supply Voltage-Max (Vsup) 5.25V
Pin Count 28
Output TTL
Base Part Number MC100H640
Time@Peak Reflow Temperature-Max (s) 30
Supply Voltage 5V
Number of Functions 1
Peak Reflow Temperature (Cel) 240
Terminal Form J BEND
Terminal Position QUAD
Voltage - Supply 4.75V~5.25V
Technology ECL
Subcategory Clock Drivers
Terminal Finish Tin/Lead (Sn80Pb20)
Number of Terminations 28
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Obsolete
JESD-609 Code e0
Published 2006
Packaging Tube
Operating Temperature 0°C~85°C
Physical
Number of Pins 28
Package / Case 28-LCC (J-Lead)
Mounting Type Surface Mount
Mount Surface Mount
