ZL30240LDF1 image
Favorite
ZL30240LDF1 image
Favorite
RoHS
RoHS RoHS compliant
Package 48-VFQFN Exposed Pad
Category Integrated Circuits (ICs) / Clock/Timing - Application Specific
Description 48-VFQFN Exposed Pad Ethernet PCI Express (PCIe) CLOCK GENERATOR OTHER QUAD application specific IC 7mm 3.63V 914MHz -40C~85C
PDF
/
Inventory: 6459
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Physical

Mounting Type Surface Mount
Package / Case 48-VFQFN Exposed Pad
Surface Mount YES
Number of Pins 48

Technical

Operating Temperature -40°C~85°C
Packaging Tape & Reel (TR)
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 48
ECCN Code EAR99
Terminal Position QUAD
Supply Voltage 2.5V
Terminal Pitch 0.5mm
Output HCSL, LVCMOS, LVDS, LVPECL
Number of Elements 2
Number of Circuits 1
Max Supply Voltage 3.63V
Min Supply Voltage 2.375V
uPs/uCs/Peripheral ICs Type CLOCK GENERATOR, OTHER
Frequency (Max) 914MHz
Input Clock, Crystal
Ratio - Input:Output 2:5
Primary Clock/Crystal Frequency-Nom 180MHz
PLL Yes
Differential - Input:Output Yes/Yes
Main Purpose Ethernet, PCI Express (PCIe)

Dimensions

Length 7mm
Width 7mm

Compliance

Radiation Hardening No
RoHS Status ROHS3 Compliant
