DS31400GN
RoHS
/
Package 256-LBGA, CSBGA
Category Integrated Circuits (ICs) / Clock/Timing - Application Specific
Description
BALL Obsolete Non-RoHS Compliant S-PBGA-B256 application specific IC e0 -40C~85C 750MHz 1.8V
PDF
/
Inventory: 1633
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mounting Type Surface Mount
Package / Case 256-LBGA, CSBGA
Surface Mount YES
Technical
Operating Temperature -40°C~85°C
Packaging Tray
JESD-609 Code e0
Part Status Obsolete
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 256
Terminal Finish TIN LEAD
Voltage - Supply 1.8V
Terminal Position BOTTOM
Terminal Form BALL
Peak Reflow Temperature (Cel) 240
Number of Functions 1
Supply Voltage 1.8V
Time@Peak Reflow Temperature-Max (s) 30
Base Part Number DS31400
Output CML, CMOS, LVDS, LVPECL, TTL
Pin Count 256
JESD-30 Code S-PBGA-B256
Qualification Status Not Qualified
Number of Circuits 1
Frequency (Max) 750MHz
Input CMOS, TTL
Ratio - Input:Output 8:14
PLL Yes
Differential - Input:Output Yes/Yes
Telecom IC Type ATM/SONET/SDH SUPPORT CIRCUIT
Main Purpose Ethernet, SONET/SDH, Stratum, Telecom
Compliance
RoHS Status Non-RoHS Compliant
