8741004BGILF
RoHS
/
Package TSSOP
Category Integrated Circuits (ICs) / Clock/Timing - Application Specific
Description
Tin INDUSTRIAL GULL WING Active (Main Purpose) IC e3 85C 160MHz 3.465V
PDF
/
Inventory: 6855
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 8 Weeks
Physical
Contact Plating Tin
Mount Surface Mount
Package / Case TSSOP
Number of Pins 24
Technical
Published 2006
JESD-609 Code e3
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1
Number of Terminations 24
ECCN Code EAR99
Max Operating Temperature 85°C
Min Operating Temperature -40°C
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Number of Functions 1
Supply Voltage 3.3V
Terminal Pitch 0.65mm
Pin Count 24
Number of Outputs 4
Operating Supply Voltage 3.3V
Temperature Grade INDUSTRIAL
Number of Circuits 1
Max Supply Voltage 3.465V
Min Supply Voltage 3.135V
Nominal Supply Current 45mA
Frequency (Max) 160MHz
Input LVDS
Logic IC Type PLL BASED CLOCK DRIVER
PLL Yes
fmax-Min 98 MHz
Dimensions
Length 7.8mm
Width 4.4mm
Thickness 1mm
Compliance
Radiation Hardening No
RoHS Status RoHS Compliant
Lead Free Lead Free
