D38999/24JD35SE
RoHS
/
Package /
Category Connectors, Interconnects / Circular Connectors
Description
Circular Connector
PDF
/
Inventory: 7310
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mount Jam Nut
Insulation Material Silicone
Shell Material Composite
Weight 21.9g
Technical
Packaging Bulk
JESD-609 Code e4
Termination Crimp
Connector Type Receptacle, Socket
Number of Positions 37
Max Operating Temperature 175°C
Min Operating Temperature -65°C
Gender Female
Contact Finish - Mating GOLD
MIL Conformance YES
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Option GENERAL PURPOSE
Total Number of Contacts 37
Orientation Straight
Mating Information MULTIPLE MATING PARTS AVAILABLE
Empty Shell NO
Backshell Type SOLID
Environmental Characteristics CORROSION/ENVIRONMENT/FLUID RESISTANT
Shell Size D
Plating Cadmium
Coupling Type THREADED
Insulation Diameter 1.3716 mm
Assembly Length 33.02mm
Durability Rating 500 cycles
Feedthrough Type No
Dimensions
Panel Thickness 3.2mm
Compliance
RoHS Status Non-RoHS Compliant
