DTS24F19-32PB
RoHS
/
Package /
Category Connectors, Interconnects / Circular Connectors
Description
DEUTSCH DTS24F19-32PB Circular Connector, DTS Series, MIL-DTL-38999 Series III Equivalent, Jam Nut Receptacle
PDF
/
Inventory: 1880
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 16 Weeks
Lifecycle Status ACTIVE (Last Updated: 2 weeks ago)
Physical
Contact Material Copper Alloy
Mount Bulkhead, Front Side Nut, Jam Nut, Panel
Mounting Type Panel Mount
Mounting Feature Bulkhead - Front Side Nut
Shell Material Aluminum
Insert Material Thermoplastic
Body Material Aluminium
Technical
Operating Temperature -65°C~200°C
Packaging Bulk
Published 2009
Series MIL-DTL-38999 Series III, DTS
JESD-609 Code e4
Feature Shielded
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Crimp
Connector Type Receptacle, Male Pins
Number of Positions 32
Color Silver
Applications Aviation, Marine, Military
Gender Receptacle
Fastening Type Threaded
Contact Finish - Mating Gold
MIL Conformance YES
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Option GENERAL PURPOSE
Total Number of Contacts 32
Orientation B
Ingress Protection Environment Sealed
Current Rating 7.5A
Shell Finish Nickel
Shell Size - Insert 19-32
Empty Shell NO
Backshell Type SOLID
Environmental Characteristics CORROSION/ENVIRONMENT/FLUID RESISTANT
Body Plating Electroless Nickel
Dimensions
Contact Finish Thickness - Mating 50.0μin 1.27μm
Compliance
Radiation Hardening No
REACH SVHC Unknown
RoHS Status Non-RoHS Compliant
Ratings Environment Resistant
