ACT90MF32SA
RoHS
/
Package /
Category Connectors, Interconnects / Circular Connectors
Description
Conn MIL-C-38999 Circular SKT 32 POS Crimp ST Flange Mount 32 Terminal 1 Port
PDF
/
Inventory: 4506
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Ratings Environment Resistant
RoHS Status Non-RoHS Compliant
REACH SVHC No SVHC
Radiation Hardening No
Dimensions
Contact Finish Thickness - Mating 50.0μin 1.27μm
Technical
ELV Compliant
Number of Contacts 32
Shell Size - Insert 19-32
Shell Finish Nickel
Current Rating 7.5A
Ingress Protection Environment Resistant
Shielding Shielded
Orientation A
Current Rating (Amps) 7.5A
Contact Finish - Mating Gold
Fastening Type Threaded
Gender Receptacle
Applications Aerospace, Military
Color Silver
Min Operating Temperature -65°C
Max Operating Temperature 200°C
Number of Positions 32
Connector Type Receptacle, Female Sockets
Termination Crimp
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Shielded
Series MIL-DTL-38999 Series III, ACT
Published 2008
Packaging Bulk
Operating Temperature -65°C~200°C
Physical
Body Material Composite
Insert Material Thermoplastic
Shell Material Composite
Mounting Feature Flange
Mounting Type Panel Mount
Mount Flanges, Panel
Contact Plating Gold
Contact Material Copper Alloy
