AFD58-14-15PX-1A
RoHS
/
Package /
Category Connectors, Interconnects / Circular Connectors
Description
STANDARD: MIL-DTL-26482POLARIZED Circular Connector
PDF
/
Inventory: 6486
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mounting Type CABLE AND PANEL
Number of Pins 16
Shell Material ALUMINUM ALLOY
Technical
ECCN Code EAR99
Connector Type MIL SERIES CONNECTOR
Additional Feature STANDARD: MIL-DTL-26482, POLARIZED
HTS Code 8536.69.40.20
Coupling Type BAYONET
Termination Type CRIMP
Shell Size 14
Environmental Characteristics ENVIRONMENT RESISTANT; MOISTURE RESISTANT
Body/Shell Style RECEPTACLE
Backshell Type SOLID
Empty Shell NO
Contact Gender MALE
Mating Information MULTIPLE MATING PARTS AVAILABLE
Shell Finish NICKEL PLATED
Reach Compliance Code unknown
Total Number of Contacts 15
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance YES
Compliance
RoHS Status Non-RoHS Compliant
