Category Connectors, Interconnects / Circular Connectors
Description Circular Connector
PDF
/
Inventory: 3000
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Physical

Contact Material Brass
Contact Plating Tin
Mount Through Hole
Housing Material Nylon
Shape Circular
PCB Mounting Orientation Right Angle

Technical

Packaging Bulk
Feature Shielded
Pbfree Code yes
Termination Solder
Connector Type Header, Receptacle, Socket
Max Operating Temperature -105°C
Min Operating Temperature -55°C
Fastening Type Pull, Push
Subcategory DIN Connectors
MIL Conformance NO
DIN Conformance YES
IEC Conformance NO
Option GENERAL PURPOSE
Orientation Right Angle
Current Rating 7.5A
Reference Standard UL, CSA
Reliability COMMERCIAL
Approval Agency CSA, UL
Number of Contacts 7
Body Breadth 0.82 inch
Contact Gender FEMALE
Housing Color Black
Body Depth 0.62 inch
Contact Resistance 15mOhm
ELV Compliant
Polarization Key POLAR PIN POSITION
Number of Ports 1
Durability 100 Cycles
EMI Shielded YES
Make First / Break Last No
Insulation Non-Insulated
Withdrawl Force-Min 4.448 N
Insertion Force-Max 13.344 N

Compliance

Flammability Rating UL94 V-0
RoHS Status RoHS Compliant

Dimensions

Length - Tail 3.56mm
Plating Thickness 2.54μm
Width 18.29mm
Length 20.07mm

Alternative Model
