213825-4
RoHS
/
Package /
Category Connectors, Interconnects / Circular Connectors
Description
Standard Circular Connector CPC RCPT ASSY SIZE 17-14,S/L
PDF
/
Inventory: 9101
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Contains Lead
Flammability Rating UL94 V-0
RoHS Status RoHS Compliant
Dimensions
Length 36.44mm
Technical
VDE Tested No
ELV Non-Compliant
Backshell Type SOLID
Empty Shell NO
Lead Length 9.35mm
Contact Gender MALE
Current Rating 13A
Depth 36.44mm
Orientation Straight
Total Number of Contacts 13
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Fastening Type Threaded
Color Black
Min Operating Temperature -40°C
Max Operating Temperature 105°C
Number of Positions 14
Connector Type Connector, Receptacle, Socket
Termination Through Hole
Pbfree Code no
Physical
Housing Material Nylon
Shell Material POLYAMIDE
Mount Flanges, Panel
Contact Plating Tin
Contact Material Brass
