TA3MLB
RoHS
/
Package /
Category Connectors, Interconnects / Circular Connectors
Description
Circular Connector
PDF
/
Inventory: 3443
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 6 Weeks
Physical
Contact Material Copper Alloy
Contact Plating Silver
Mount Free Hanging
Mounting Type Free Hanging (In-Line)
Insulation Material Plastic
Shell Material Copper Alloy
Insert Material Polyphenylene Sulfide (PPS)
Backshell Material, Plating Thermoplastic
Technical
Operating Temperature -55°C~85°C
Packaging Bulk
Published 2010
Series Tini Q-G? TA
Feature Backshell, Cable Clamp
Part Status Obsolete
Moisture Sensitivity Level (MSL) Not Applicable
Termination Solder
Connector Type Receptacle, Male Pins
Number of Positions 3
Max Operating Temperature 85°C
Min Operating Temperature -55°C
Color Black
Applications Audio
Voltage - Rated 125VAC
Fastening Type Latch Lock
Contact Finish - Mating Silver
Current Rating (Amps) 5A
Orientation Keyed
Shielding Shielded
Current Rating 5A
Shell Finish Chrome
Shell Size - Insert Mini XLR
Number of Contacts 3
Cable Opening 0.115 ~ 0.190 (2.92mm ~ 4.83mm)
Compliance
Material Flammability Rating UL94 V-0
RoHS Status Non-RoHS Compliant
Lead Free Contains Lead
