TA3FLB
RoHS
/
Package /
Category Connectors, Interconnects / Circular Connectors
Description
Conn Mini XLR Connector F 3 POS Solder ST Cable Mount 3 Terminal 1 Port
PDF
/
Inventory: 8596
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Contains Lead
RoHS Status Non-RoHS Compliant
Dimensions
Length 48mm
Technical
Cable Opening 0.115 ~ 0.190 (2.92mm ~ 4.83mm)
Number of Ports 1
Coupling Type SNAP
Max Current Rating 5A
Max Voltage Rating (AC) 125V
Backshell Type SOLID
Empty Shell NO
Mating Information MULTIPLE MATING PARTS AVAILABLE
Shell Size - Insert Mini XLR
Shell Finish Chrome
Current Rating 5A
Shielding Shielded
Orientation Keyed
Total Number of Contacts 3
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Contact Finish - Mating Silver
Fastening Type Latch Lock
Additional Feature POLARIZED
Voltage - Rated 125VAC
Applications Audio
Color Black
Number of Positions 3
Connector Type Plug, Female Sockets
Termination Solder
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Obsolete
Pbfree Code no
Feature Backshell, Cable Clamp
JESD-609 Code e4
Series Tini Q-G? TA
Published 2001
Packaging Bulk
Operating Temperature -55°C~85°C
Physical
Backshell Material, Plating Thermoplastic
Shell Material Copper Alloy
Insulation Material Plastic
Mounting Type Free Hanging (In-Line)
Mount Cable, Free Hanging
Contact Material Copper Alloy
