R5FZ
RoHS
RoHS compliant
RoHS compliantPackage Metal
Category Connectors, Interconnects / Circular Connectors
Description
LATCHED Circular Connector
PDF
/
Buying Options
Total Price: USD $69.25
Unit Price: USD $69.247621
≥1 USD $69.247621
≥10 USD $65.327941
≥100 USD $61.630132
≥500 USD $58.141638
≥1000 USD $54.850597
Inventory: 5595
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 12 Weeks
Physical
Contact Material Copper Alloy
Contact Plating Nickel, Silver
Mount Cable, Free Hanging
Mounting Type Free Hanging (In-Line), Right Angle
Package / Case Metal
Shell Material Zinc Alloy
Insert Material Thermoplastic
Backshell Material, Plating Zinc Alloy, Nickel
Technical
Packaging Bulk
Published 2004
Series Q-G? R
JESD-609 Code e4
Feature Backshell, Cable Clamp, Ground, Strain Relief
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Solder Cup
Connector Type Plug, Female Sockets
Number of Positions 5
Applications Audio, Industrial, Instrumentation, Medical
Gender Female
Voltage - Rated 125VAC
Additional Feature LATCHED
Fastening Type Latch Lock
Contact Finish - Mating Silver
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Option GENERAL PURPOSE
Orientation Keyed
Depth 27.5mm
Reach Compliance Code not_compliant
Current Rating 7.5A
Shell Finish Nickel
Shell Size - Insert XLR
Number of Ports 1
Number of Poles 5
Cable Opening 0.100 ~ 0.285 (2.54mm ~ 7.24mm)
Dimensions
Length 46.85mm
Compliance
RoHS Status ROHS3 Compliant
