Package /
Category Connectors, Interconnects / Circular Connectors
Description Circular Connector
PDF
/
Inventory: 1604
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

Lead Free Lead Free
RoHS Status ROHS3 Compliant

Dimensions

Length 26mm

Technical

Number of Ports 1
Coupling Type SNAP
Max Current Rating 15A
Body/Shell Style RECEPTACLE
Backshell Type SOLID
Empty Shell NO
Mating Information MULTIPLE MATING PARTS AVAILABLE
Shell Size - Insert XLR
Shell Finish Nickel
Current Rating 15A
Depth 36.69mm
Shielding Shielded
Orientation Keyed
Total Number of Contacts 3
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Contact Finish - Mating Silver
Fastening Type Latch Lock
Voltage - Rated 125V
Gender Female
Applications Audio, Instrumentation
Number of Positions 3
Connector Type Plug, Female Sockets
Termination Solder
Number of Terminations 4
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Obsolete
Feature Ground
JESD-609 Code e4
Series Q-G? E
Packaging Bulk
Operating Temperature -55°C~85°C

Physical

Insert Material Thermoplastic
Shell Material Zinc Die Cast
Insulation Material Plastic
Mounting Feature Flange
Mounting Type Panel Mount
Mount Flanges, Panel
Contact Material Copper Alloy
