05GM3M
RoHS
/
Package /
Category Connectors, Interconnects / Circular Connectors
Description
CONN PLUG MALE DIN 3POS SOLDER
PDF
/
Inventory: 1847
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Contact Material NOT SPECIFIED
Contact Plating Nickel, Tin
Mount Cable, Free Hanging
Mounting Type Free Hanging (In-Line)
Shell Material Zinc Die Cast
Backshell Material, Plating Plastic
Technical
Packaging Bulk
Published 2005
Feature Backshell, Cable Clamp, Strain Relief
Part Status Obsolete
Moisture Sensitivity Level (MSL) Not Applicable
Termination Solder
ECCN Code EAR99
Connector Type Plug, Male Pins
Number of Positions 3
Color Gray, Silver
Gender Male
Voltage - Rated 34V
Fastening Type Push-Pull
Subcategory DIN Connectors
Contact Finish - Mating Tin
MIL Conformance NO
DIN Conformance YES
IEC Conformance NO
Option GENERAL PURPOSE
Total Number of Contacts 3
Orientation 2
Shielding Shielded
Current Rating 3A
Shell Finish Nickel
Shell Size - Insert DIN 180 Degree
Reliability COMMERCIAL
Body Length or Diameter 0.669 inch
Body Breadth 0.669 inch
Rated Current (Signal) 3A
Contact Style RND PIN-SKT
Polarization Key POLAR PIN POSITION
Dielectric Withstanding Voltage 500VAC V
Number of Ports 1
Insertion Force-Max 8.0064 N
EMI Shielded NO
Compliance
RoHS Status Non-RoHS Compliant
Lead Free Contains Lead
