JBXER3G14FCSDSR
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Circular Connectors
Description
CONN RCPT FMALE 14POS GOLD CRIMP
PDF
/
Inventory: 6547
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 18 Weeks
Physical
Mount Bulkhead, Panel, Rear Side Nut
Mounting Type Panel Mount
Mounting Feature Bulkhead - Rear Side Nut
Shell Material Brass
Insert Material Polyetheretherketone (PEEK)
Technical
Operating Temperature -40°C~125°C
Packaging Bulk
Series JBX
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Crimp
Connector Type Receptacle, Female Sockets
Number of Positions 14
Color Silver
Applications Industrial, Instrumentation, Medical, Telecommunications
Voltage - Rated 830V
Fastening Type Push-Pull
Contact Finish - Mating Gold
Orientation G
Shielding Shielded
Ingress Protection IP40
Current Rating 9A
Shell Finish Chrome over Nickel
Shell Size - Insert 3
Dimensions
Contact Finish Thickness - Mating 19.7μin 0.50μm
Compliance
Material Flammability Rating UL94 V-0
RoHS Status ROHS3 Compliant
