8D723S35PC
RoHS
/
Package /
Category Connectors, Interconnects / Circular Connectors
Description
8D 100C 100#22D PIN J/N
PDF
/
Inventory: 1342
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Dimensions
Width (mm) 52.40
Length (mm) 32.50
Height (mm) 52.40
Height (in) 2.06
Length (in) 1.28
Width (in) 2.06
Technical
Number of cavity #22D 100
Environment RoHS
Vrms (Sea Level) 1300
Sealing Level (IP) 67
Temperature Min. (°F) -85
Temperature Min. (°C) -65
Temperature Max. (F°) 392
Temperature Max. (°C) 200
Salt Spray (h) 500
Layout 35
Coupling Thread
Mating Cycles 500
Plating Nickel
Shell Size 23
Contact Gender Pin (Male)
Number of Contacts 100
Function signal
Shielding Yes
Contact Type Crimp
Connector Type Receptacle
Physical
Nut Material Stainless Steel
Receptacle Mounting Type Jam Nut Receptacle
Insert Material Peek
Shell Material Stainless Steel
Contact Plating Gold
