8D515F15AE
RoHS
/
Package /
Category Connectors, Interconnects / Circular Connectors
Description
8D 15C 14#20 1#16 PIN PLUG
PDF
/
Inventory: 1709
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Shell Material Aluminium
Insert Material Peek
Technical
Connector Type Plug
Shielding Yes
Function signal
Number of Contacts 15
Contact Gender Pin (Male)
Shell Size 15
Plating Nickel
Mating Cycles 500
Coupling Thread
Layout 15
Salt Spray (h) 48
Temperature Max. (°C) 200
Temperature Max. (F°) 392
Temperature Min. (°C) -65
Temperature Min. (°F) -85
Sealing Level (IP) 67
Vrms (Sea Level) 1800
Environment RoHS
Plug Type Straight Plug
Number of cavity #16 15
#16 contact rating (A) 13.00
Dimensions
Width (in) 1.28
Length (in) 1.28
Height (in) 1.28
Height (mm) 32.50
Length (mm) 32.50
Width (mm) 32.50
