8D117Z06SA
RoHS
/
Package /
Category Connectors, Interconnects / Circular Connectors
Description
Circular Connector
PDF
/
Inventory: 8645
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Contact Plating Gold
Shell Material Aluminium
Insert Material Peek
Receptacle Mounting Type In-Line Receptacle
Technical
Connector Type Receptacle
Contact Type Crimp
Shielding Yes
Function signal
Number of Contacts 6
Contact Gender Socket (Female)
Shell Size 17
Plating Black Zinc Nickel
Mating Cycles 500
Coupling Thread
Layout 06
Salt Spray (h) 500
Temperature Max. (°C) 200
Temperature Max. (F°) 392
Temperature Min. (°C) -65
Temperature Min. (°F) -85
Sealing Level (IP) 67
Vrms (Sea Level) 1800
Environment RoHS
Plating detail Zinc nickel (conductive) -65°C to +200°C
#12 contact rating (A) 23.00
Number of cavity #12 6
Dimensions
Width (in) 1.19
Length (in) 1.24
Height (in) 1.19
Height (mm) 30.10
Length (mm) 31.40
Width (mm) 30.10
