8D115F05AD
RoHS
/
Package /
Category Connectors, Interconnects / Circular Connectors
Description
Circular Connector
PDF
/
Inventory: 7029
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Shell Material Aluminium
Insert Material Peek
Receptacle Mounting Type In-Line Receptacle
Dimensions
Width (mm) 25.40
Length (mm) 31.40
Height (mm) 25.40
Height (in) 1.00
Length (in) 1.24
Width (in) 1.00
Technical
#16 contact rating (A) 13.00
Number of cavity #16 5
Environment RoHS
Vrms (Sea Level) 2300
Sealing Level (IP) 67
Temperature Min. (°F) -85
Temperature Min. (°C) -65
Temperature Max. (F°) 392
Temperature Max. (°C) 200
Salt Spray (h) 48
Layout 05
Coupling Thread
Mating Cycles 500
Plating Nickel
Shell Size 15
Contact Gender Pin (Male)
Number of Contacts 5
Function signal
Shielding Yes
Connector Type Receptacle
