8D113W04AC
RoHS
/
Package /
Category Connectors, Interconnects / Circular Connectors
Description
Circular Connector
PDF
/
Inventory: 2753
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Shell Material Aluminium
Insert Material Peek
Receptacle Mounting Type In-Line Receptacle
Technical
Connector Type Receptacle
Shielding Yes
Function signal
Number of Contacts 4
Contact Gender Pin (Male)
Shell Size 13
Plating Cadmium
Mating Cycles 500
Coupling Thread
Layout 04
Salt Spray (h) 500
Temperature Max. (°C) 175
Temperature Max. (F°) 347
Temperature Min. (°C) -65
Temperature Min. (°F) -85
Sealing Level (IP) 67
Vrms (Sea Level) 1800
Plating detail Olive drab Cadmium (conductive) -65°C to +175°C
Number of cavity #16 4
#16 contact rating (A) 13.00
Dimensions
Width (in) 0.88
Length (in) 1.24
Height (in) 0.88
Height (mm) 22.20
Length (mm) 31.40
Width (mm) 22.20
