8D111F04SC
RoHS
/
Package /
Category Connectors, Interconnects / Circular Connectors
Description
Circular Connector
PDF
/
Inventory: 2500
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Dimensions
Width (mm) 19.00
Length (mm) 31.40
Height (mm) 19.00
Height (in) 0.75
Length (in) 1.24
Width (in) 0.75
Technical
#20 contact rating (A) 7.30
Number of cavity #20 4
Environment RoHS
Vrms (Sea Level) 1800
Sealing Level (IP) 67
Temperature Min. (°F) -85
Temperature Min. (°C) -65
Temperature Max. (F°) 392
Temperature Max. (°C) 200
Salt Spray (h) 48
Layout 04
Coupling Thread
Mating Cycles 500
Plating Nickel
Shell Size 11
Contact Gender Socket (Female)
Number of Contacts 4
Function signal
Shielding Yes
Contact Type Crimp
Connector Type Receptacle
Physical
Receptacle Mounting Type In-Line Receptacle
Insert Material Peek
Shell Material Aluminium
Contact Plating Gold
