8D015K05AB
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Circular Connectors
Description
8D 5C 5#16 PIN RECP
PDF
/
Inventory: 8790
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Technical
Coupling Type THREADED
Termination Type CRIMP
Shell Size 15
Environmental Characteristics ENVIRONMENT/FLUID RESISTANT
Body/Shell Style RECEPTACLE
Backshell Type SOLID
Empty Shell YES
Contact Gender MALE
Mating Information MULTIPLE MATING PARTS AVAILABLE
Total Number of Contacts 5
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance YES
Contact Finish - Mating NOT SPECIFIED
Additional Feature STANDARD: MIL-DTL-38999, EMI SHIELDED, POLARIZED
Connector Type MIL SERIES CONNECTOR
Part Status Active
Pbfree Code yes
Physical
Shell Material STAINLESS STEEL
Mounting Type CABLE AND PANEL
Contact Material NOT SPECIFIED
