1694363 image
Favorite
1694363 image
Favorite
RoHS
RoHS RoHS compliant
Package /
Category Connectors, Interconnects / Circular Connectors
Description Conn Sensor Actuator F 3 POS Solder ST Thru-Hole 3 Terminal 1 Port
PDF
/
Buying Options
Total Price: USD $15.98
Unit Price: USD $15.9808
≥1 USD $15.9808
≥10 USD $14.70392
≥100 USD $13.585264
≥500 USD $12.945944
≥1000 USD $12.874822
Inventory: 75
Minimum: 1
-
+

Technical Details

Compliance

Ratings Dust Tight, IP67, Waterproof
Lead Free Lead Free
RoHS Status RoHS Compliant
Material Flammability Rating UL94 HB

Technical

Thread Size M8
Number of Ports 1
Plating Brass, Nickel
Max Current Rating 4A
Backshell Type SOLID
Empty Shell NO
Contact Gender Female
Shell Size - Insert M8-3
Shell Finish Nickel
Current Rating 4A
Reach Compliance Code unknown
Depth 14mm
Ingress Protection IP67 - Dust Tight, Waterproof
Orientation A
Total Number of Contacts 3
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Contact Finish - Mating Gold
Fastening Type Threaded
Voltage - Rated 50VAC 60VDC
Gender Male
Color Silver
Number of Positions 3
Connector Type Receptacle, Female Sockets
Termination Solder
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e4
Series DSI
Published 2011
Packaging Bulk
Operating Temperature -40°C~85°C

Physical

Insert Material Polyamide (PA66), Nylon 6/6
Weight 13.650012g
Shell Material Brass
Mounting Feature Bulkhead - Front Side Nut
Mounting Type Panel Mount, Through Hole
Mount Bulkhead, Panel, Screw, Through Hole
Contact Material Copper Tin

Supply Chain

Factory Lead Time 4 Weeks
