RoHS
/
Package /
Category Connectors, Interconnects / Circular Connectors
Description CONN DISTRIBUTOR 4POS IDC
PDF
/
Inventory: 1162
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Supply Chain

Factory Lead Time 3 Weeks

Physical

Contact Material Copper
Contact Plating Silver, Tin
Mount Cable, Free Hanging
Mounting Type Free Hanging (In-Line)
Number of Pins 4
Shell Material Polyamide (PA), Nylon
Housing Material Polyamide
Weight 99.999994g
Insert Material Polyamide (PA), Nylon
Backshell Material, Plating Polyamide (PA), Nylon

Technical

Operating Temperature -40°C~100°C
Packaging Bulk
Published 2009
Series QPD
JESD-609 Code e4
Feature Backshell
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination IDC
ECCN Code EAR99
Connector Type Distributor
Number of Positions 4 (3 + PE)
Color Black, Green
Voltage - Rated 630V
Fastening Type Threaded
Contact Finish - Mating Silver
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Option GENERAL PURPOSE
Total Number of Contacts 4
Orientation Straight
Ingress Protection IP66/68/69K - Dust Tight, Water Resistant, Waterproof
Current Rating 20A
Contact Gender Male
Empty Shell NO
Backshell Type SOLID
Cable Opening 0.236 ~ 0.394 (6.00mm ~ 10.00mm)
Wire/Cable Diameter 10 mm

Dimensions

Length 76mm

Compliance

Material Flammability Rating UL94 V-0
RoHS Status RoHS Compliant
Ratings Dust Tight, IP68, Waterproof
