1557581
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Circular Connectors
Description
Conn M12 Circular PIN 8 POS Solder ST Thru-Hole 8 Terminal 1 Port
PDF
/
Buying Options
Total Price: USD $10.25
Unit Price: USD $10.24723
≥1 USD $10.24723
≥10 USD $9.6672
≥100 USD $9.12
Inventory: 463
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 9 Weeks
Physical
Contact Material Copper Zinc
Mount Panel, Through Hole
Mounting Type Through Hole
Weight 3.660008g
Insert Material Polyamide (PA66), Nylon 6/6
Technical
Operating Temperature -25°C~85°C
Packaging Bulk
Published 2012
Series SACC
JESD-609 Code e4
Feature Board Guide, Insert Only, Requires Shell
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Solder
Connector Type Insert, Male Pins
Number of Positions 8
Voltage - Rated 30V
Fastening Type Push, Twist
Contact Finish - Mating Gold
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Total Number of Contacts 8
Orientation A
Shielding Shielded
Ingress Protection IP67 - Dust Tight, Waterproof
Reach Compliance Code unknown
Current Rating 2A
Shell Size - Insert M12-8
Contact Gender Male
Empty Shell NO
Backshell Type SOLID
Body/Shell Style PLUG
Max Current Rating 2A
Number of Ports 1
Thread Size M12
Compliance
Material Flammability Rating UL94 V-0
RoHS Status RoHS Compliant
Lead Free Lead Free
Ratings Dust Tight, IP67, Waterproof
